240v Hook Up Kit with Twin 240v Sockets (Choice of Colour), Twin Poled RCD & MCB Consumer Unit – Inlet – Black, White or Underslung


This compact mini consumer unit is an essential safety device for fitting a 240V system to a caravan, campervan, motorhome or boat.

The deluxe enclosure contains a fast-acting 25A, 30mA RCD with a ‘test ‘ function and double-pole, 6A and 10A miniature circuit breakers. It also features a reverse polarity indicator warning light that illuminates red if the live and neutral at the site supply are reversed.

It comes pre-wired with installation instructions and the clear cover unclips from the enclosure to allow access to the screws. ‘Slide-out’ tabs are located at the top and bottom of the unit to allow cable entry.

Note: If you are unsure about installing this system yourself, please consult a qualified electrician.

  • RCD: 25A, 30mA fast acting with test switch, Type A
  • MCB: 1 x 6A double pole, 1 x 10A double pole, C-curve
  • Enclosure material: Plastic
  • Reverse-polarity indicator: Yes
  • Consumer unit dims: 182 (H) x 164 (W) x 97 (D) mm

The 240v hook-up inlet is a component which would be integrated into the vehicle body allowing you to hook your van up to a 240 volt supply at any campsite

Non underslung versions have a lever latch to clip the lead firmly in place and also come with a padded gasket to ensure a water tight seat to your van. A sprung front ensures the lid doesn’t flap around when open. Compact and neat and easy to connect.

The kit comes with a choice of 4 colours of socket surround: Flatline Silver, Graphite, Matt Black or Chrome Square

SKU: P-EL-CPN-HU Category:

Additional information

240v Surround Colour

Flatline Silver, Graphite, Matt Black, Chrome Square

Hook Up Inlet

Black, White, Underslung
