Victron Energy – Battery Switch – 275 Amp – New Product

This battery switch offers a removable knob for isolation/safety purposes and an ergonomic design. The unit meets ISO8846 Ignition Protection and can be surface or panel mounted.

Specification;

Part No: VBS127010010
Max.continuous current: 275A
One minute rating: 450 A
Cranking rating: 1200 A
Voltage rating: 48 V
Terminal material: Tin-plated copper
Hex nut material: Tin-plated copper
Terminal diameter: 3/8inch / 9.53mm
Recommended torque: 70lbf-inch / 8N-m
Base material: Glassfiber reinforced nylon
Weight: 0.4 lb / 0.2 kg
Dimensions (hxwxd): 1.8 x 6.0 x 1.25inch, 69 x 69 x 73mm
Mounting: Surface or rear panel mount
Ignition protected: ISO8846 / SAE J117
